EtherNet/IP Communication UnitUC1-EP
Management and control of sensors over a network
- Compact adapter to EtherNet/IP network
- Mixed connection with fiber sensor and displacement sensor amplifiers
- Wiring and space saving
NEW
Compatible with digital fiber amplifiers D4RF Series
Specifications
| Model | UC1-EP | |
|---|---|---|
| Network | EtherNet/IP*1 | |
| Supported version | EtherNet/IP adapter | |
| Authentication version | CT16 | |
| Compliant standards | IEEE802.3u | |
| Distance between nodes | Within 100 m | |
| Transmission speed | 10/100 Mbps | |
| Cable | STP Category 5/5e or higher | |
| Supported functions | Implicit Message (Class1 service) Explicit Message (Class3 message, UCMM) ACD (Address Conflict Detection) DLR (Device Level Ring) Static IP address DHCP BOOTP |
|
| Indicators | Power indicator: green (PWR) Network status: red/green (NS) Module status: red/green (MS) Operation indicator: green (SYSTEM) PORT1 indicator: green (L/A1) PORT2 indicator: green (L/A2) |
|
| Connection type | Connector type: M8 4-pin plug connector | |
| Data | Cyclic communication (transmission: max. 40 bytes, receipt: max. 4 bytes) Acyclic communication |
|
| Connected devices | Connectable models | Interconnection main and expansion unit of D4RF*2/D3WF Series Main and expansion unit of CDA Series |
| Number of units connected | Max. 16 units*3 (one CDA unit accounts for two units) | |
| Connection type | 5-pin connector for interconnection (functions as end unit for interconnection) | |
| Rating | Supply voltage | 12 to 24 VDC including ripple (p-p) ±10% |
| Current consumption | 3 W max. | |
| Warm-up time | 1.5 s or less | |
| Protection circuit | Reverse connection protection | |
| Environmental resistance | Ambient temperature/humidity | −25 to +55°C/35 to 85% RH (no freezing or condensation) |
| Storage temperature/humidity | −40 to +70°C/35 to 85% RH (no freezing or condensation) | |
| Vibration resistance | 10 to 55 Hz, double amplitude 1.5 mm, 2 hours in X, Y and Z directions | |
| Shock resistance | 500 m/s2 (approx. 50 G), 3 times in X, Y and Z directions | |
| Degree of protection | IP50 | |
| Conforming laws and regulations | EMC | EU EMC directive (2014/30/EU) |
| Environment | EU RoHS directive (2011/65/EU), China RoHS (MIIT Order No.32) | |
| Applicable regulations | EN 61000-6-2, EN 55011 | |
| NRTL certification | UL Recognized Component Programmable Controllers Certified for US and Canada. |
|
| Company standards | Noise resistance Feilen Level 3 cleared | |
| Mounting | 35 mm DIN rail (conductive surface) | |
| Material | Polycarbonate | |
| Included items | Instruction manual, M12 protective cap, end plate × 2 | |
*1: Ethernet/IP is a registered trademark of ODVA (Open DeviceNet Vendor Association Inc.).
*2: To use D4RF Series with this unit, the software version of UC1-EP must be V1.2.0.
Please contact us for information on products with software versions V1.0.9 or V1.1.9.
The software version is indicated on the product label as follows.
*3: The ambient temperature and maximum number of interconnections are shown below.
D4RF Series
| Upper and lower limits of ambient temperature |
-25 to +55 ºC | -25 to +55 ºC | -25 to +50 ºC | -25 to +45 ºC |
| Number of connected units | 1 | 2 | 3 to 5 | 6 to 16 |
D3WF Series
| Upper and lower limits of ambient temperature |
-25 to +55 ºC | -25 to +50 ºC | -25 to +45 ºC |
| Number of connected units | 1 to 3 | 4 to 8 | 9 to 16 |
CDA-M + CDA-S
| Upper and lower limits of ambient temperature |
-25 to +50 ºC |
| Number of connected units | 1 to 8 |
CDA-DM2 + CDA-S
| Upper and lower limits of ambient temperature |
-25 to +50 ºC | -25 to +45 ºC |
| Number of connected units | 1 | 2 to 8 |
