TOF Type with Built-in Digital PanelTOF-DL Series
Smallest TOF sensor in class*
*Among devices equipped with displays. Optex FA examination performed December 2018.
- Analog output type and 3-control-output type
- TOF(Time-Of-Flight principle)
- Built-in digital display for simple setup
- IO-Link connection supported: IO-Link type
Detect from up to 2.5 m away.
“Visualize” distances with the TOF-DL compact sensor.
The FASTUS TOF-DL Series is the smallest TOF sensor*1.
This ultra-compact laser distance sensor is capable of detecting at distances of up to 2.5 m.
With a built-in digital display, conﬁguring settings is simple.
Notably, the TOF-DL Series is most useful with applications requiring height and target distance control, such as level and position detection and loop control at a manufacturing site.
*1 Among devices equipped with displays. Optex FA examination performed December 2018.
The TOF principle measures the time it takes a pulse-emitted laser to hit a target and return, and the measurement is then converted into distance. With strong resistance to inﬂuences from the target’s surface conditions, this principle is capable of producing stable detection.
Easy-to-See Digital Display
With its ultra-compact size, the TOF-DL Series is equipped with a three-digit, easy-to-see digital display.
The display allows users to check the distance showing numerical values.
This digital display also makes threshold adjustments easy.
Easy-to-See Indicators and Stability Output
The indicators used on the TOF-DL Series allow for easy visibility from any angle.
In addition, users are able to switch output 1 to Stability Output.
Stability Output turns ON (Central indicator = Green) when detection is stable and turns OFF (Central indicator = Red) when detection is not possible.
Class 1 Laser Light Source
The Class 1 laser used in the TOF-DL Series opens the door to
long-distance measuring at up to 2.5 m without sacrificing eye safety.
In addition, the spot is clearly visible, making light axis alignments easy.
