Fiber-Optic CablesNF Series Flexible type (R1 mm, R2 mm)

DOWNLOAD

Easy to handle Fiber-Optic Cables with a bending radius of 1 mm or 2 mm

  • Extra space is unnecessary as the bending radius is 1 mm or 2 mm. Also prevents snagging
  • 30 types are available, including through-beam types and diffuse-reflective types
NF Series Flexible type (R1 mm, R2 mm)

Thanks to highly-flexible fibers

The Fiber-Optic Cables for the flexible type (R1 mm) has an allowable bending radius of 1 mm ! Cable can be installed without worrying about damaging the fiber.

*If fibers are mounted on moving parts, please select flexible type Fiber-Optic Cables.

  • Standard fiber

    Space is needed because the bending radius is large. Also, you may have problems when snagged.

  • Flexible fiber

    Extra space is unnecessary as the bending radius is 1 mm.
    No more worrying about snagging.

Straight view / Side view switchable type

The NF-TR14 can be used as a side view type by bending the fiber cable to fit the slit in the side of the nut. This Fiber-Optic Cable allows switching between side view and straight view according to mounting conditions.
