Options/Accessories

Connector cables

• Straight



  M84CN-2S

  Cable length: 2 m

  M84CN-5S

  Cable length: 5 m

  M84CN-10S

  Cable length: 10 m

  Minimum bending radius: 24 mm
  (When fixed in place)

• L-shaped



  M84CN-2L

  Cable length: 2 m

  M84CN-5L

  Cable length: 5 m

  M84CN-10L

  Cable length: 10 m

  Minimum bending radius: 24 mm
  (When fixed in place)

Protective mounting bracket　LK Series

• Ultra-durable 2 mm thick type
• Rust-resistant stainless steel
• Sensor is firmly secured using M3 Hex socket head cap screws
• The bracket is also firmly secured using M6 screws

•

  LK-S01

•

  LK-S02

Mounting bracket

•

  For cable type
  Floor-mounted

  BEF-W100-B

•

  For connector type
  Back-mounted

  BEF-W100-A

  Cannot be used with
  connector cable M84CN-□L

•

  For cable type
  Floor-mounted

  BEF-W100-C
