Coaxial Retro-reflective SensorsZR-X Series

DOWNLOAD

  • Coaxial optical system for stable detection
  • Zero detection dead area from a reflector
  • Fast response of 250μs
ZR-X Series

Output circuit diagram

  • NPN output

  • PNP output

  • Connector type

  • Connecting

    ▪ ① to ④ are connector pin No.

    Notes

    ▪ When using a switching regulator for the power supply, be sure to ground the frame ground terminal.
    ▪ Because wiring sensor wires with high-voltage wires or power supply wires can result in malfunctions due to noise, which can cause damage, make sure to wire separately.
    ▪ Avoid using the transient state while the power is on (approx. 100 ms).
    ▪ The connector direction is fixed as the drawing below when you use L-shaped connector cable. Be aware that rotation is not possible.

Dimensions

Unit : mm

Cable type

Connector type

Connector cable

  • M84CN-2S, M84CN-5S, M84CN-10S

  • M84CN-2L, M84CN-5L, M84CN-10L

Mounting bracket

  • BEF-W100-B

  • BEF-W100-A

Protective mounting bracket

  • LK-S01

  • LK-S02

Reflector

  • V-61: Standard

  • V-42: Small

  • P45A: Vertical
