Specifications
Technical Data
| Illumination color | White | Blue | Red |
|---|---|---|---|
| Color temperature / Peak wavelength | 6,500 K | 470 nm | 630 nm |
| Input voltage | 12 VDC | ||
| Degradation of LED | For brightness to drop 10% after 10,000 hours (Dimming value setting = 100%, 30°C) *Typical values | ||
| Classification (IEC62471: 2006) | Exempt group | Risk Group 1 (Low-Risk) | Exempt group |
| Applicable regulations/standards | EMC (2014/30/EU), RoHS (2011/65/EU, MIIT Order No.32) / EN 61326-1:2013 | ||
| Protection rating | IP40 (IEC 60529: 1989/A1: 1999 + A2: 2013) | ||
| Ambient temperature/humidity | 0 to 40°C / 35 to 85% RH (no condensation) | ||
| Storage temperature/humidity | -20 to 70°C / 35 to 95% RH (no condensation) | ||
| Vibration resistance | 10 to 55 Hz; amplitude 1.5 mm; 2 hours in each of the X, Y, and Z directions | ||
| Shock resistance | 10 G, 3 times in each of the X, Y, and Z directions | ||
| Material | Housing: Aluminum alloy and stainless steel | ||
| Options | Scratch-resistant cover, polarizing plate, and bracket | ||
Emission spectrum diagram
