Discontinued Products
- Some models in this product series have been discontinued.
- Discontinued Models
-
- OPB-5015W2
- OPB-5015W
- OPB-5015B
- OPB-5015R
- OPB-10015W2
- OPB-10015W
- OPB-10015R
- OPB-10015B
- OPB-15015W2
- OPB-15015W
- OPB-15015B
- OPB-15015R
- OPB-20015W2
- OPB-20015W
- OPB-20015B
- OPB-20015R
- OPB-25015W2
- OPB-25015W
- OPB-25015B
- OPB-25015R
- OPB-30015W2
- OPB-30015W
- OPB-30015B
- OPB-30015R
- OPB-45015W2
- OPB-45015W
- OPB-5015W2-B
- OPB-5015W-B
- OPB-5015B-B
- OPB-5015R-B
- OPB-10015W2-B
- OPB-10015W-B
- OPB-10015B-B
- OPB-10015R-B
- OPB-15015W2-B
- OPB-15015W-B
- OPB-15015B-B
- OPB-15015R-B
- OPB-ST10015W
- OPB-ST15015W
- OPB-10015G
- OPB-10015G-B
- OPB-15015G
- OPB-20015G
- OPB-25015G
- OPB-30015G
- OPB-5015G
- OPB-5015G-B
Specifications
Technical Data
| Series | OPB Series | OPB-ST Series | |||
|---|---|---|---|---|---|
| Illumination color | White (W2) | White | Blue | Red | White |
| Color temperature / Peak wavelength | 6,500 K | 7,000 K | 470 nm | 630 nm | 7,000 K |
| Input voltage | 12 VDC | 18 VDC | |||
| Degradation of LED | For brightness to drop 10% after 10,000 hours (Dimming value setting = 100%, 30℃) *Typical values | ||||
| Classification (IEC62471: 2006) | Risk Group 1 (Low-Risk) | ||||
| Applicable regulations/standards | EMC (2014/30/EU), RoHS (2011/65/EU, MIIT Order No.32) / EN 61326-1:2013 | ||||
| Protection rating | IP40 (IEC 60529: 1989 / A1: 1999 + A2: 2013) | ||||
| Ambient temperature/humidity | 0 to 40℃ / 35 to 85% RH (no condensation) | ||||
| Storage temperature/humidity | -20 to 70℃ / 35 to 95% RH (no condensation) | ||||
| Vibration resistance | 10 to 55 Hz; amplitude 1.5 mm; 2 hours in each of the X, Y, and Z directions | ||||
| Shock resistance | Approximately 10 G, 3 times in each of the X, Y, and Z directions | ||||
| Material | Housing: Aluminum and PBT, Lens: PC (UV-resistant) | ||||
| Options | Diffusion plate (60% or 80%), transparent cover, polarizing plate, bracket | ||||
Emission spectrum diagram
