Discontinued Products
- This model has been discontinued.
For suitable alternatives, please feel free to contact us.
Specifications
Technical Data
| Illumination color | White |
|---|---|
| Color temperature | 7,000 K |
| Input voltage | 12 VDC |
| Degradation of LED | For brightness to drop 10% after 10,000 hours (Dimming value setting = 100%, 30°C) *Typical values |
| Classification (IEC62471: 2006) | Risk Group 1 (Low-Risk) |
| Applicable regulations/standards | EMC (2014/30/EU), RoHS (2011/65/EU, MIIT Order No.32) / EN 61326-1:2013 |
| Protection rating | IP40 (IEC 60529: 1989 / A1: 1999 + A2: 2013) |
| Ambient temperature/humidity | 0 to 40°C, 35 to 85% RH (no condensation) |
| Storage temperature/humidity | -20 to 70°C, 35 to 95% RH (no condensation) |
| Vibration resistance | 10 to 55 Hz; amplitude 1.5 mm; 2 hours in each of the X, Y, and Z directions |
| Shock resistance | Approximately 10 G, 3 times in each of the X, Y, and Z directions |
| Material | Housing: Aluminum and PBT, Lens: PC (UV-resistant) |
| Options | Diffusion plate (60% or 80%), transparent cover, polarizing plate, bracket |
Emission spectrum diagram
