We indroduce the fiearues of Best-in-class, All-in-one Sensors CD2H Series on our YouTube video.
You can check the demonstrations to detect black objects that absorb light or curved metal objects which is difficult to detect with displacement sensors.
-
OLED display can display various measurement values and languages
- CD2H Series can visualize a wide variety of information.
7 languages supported: English, Japanese, Simplified Chinese, Traditional Chinese, Korean, German, Spanish.
Four types of measurement value displays are selectable: relative value, absolute value, bar graph, and analog value.
Visibility and operability have been improved compared to the conventional products.
-
- Waveform of received light can be displayed on the sensor itself
- CD2H Series can display waveform of received light on the sensor itself.
The received light amount can be seen at a glance!
Monitoring of waveform on the sensor itself can be check the received light amount and ambient light. Ensures the ideal installation angle.
-
- Stable detection even on metal objects with glossy surface
- The best-in-class preformation is achieved by the ultra-sensitive ATMOS image sensor that was originally developed for the most advanced displacement sensor, CDX Series.
CD2H Series is able to perform measurement even curved metal objects with gloss, which are difficult to detect with displacement sensors.
ATMOS: Auto Tuning C-MOS
-
- Stable detection even on black objects
- The best-in-class preformation is achieved by the ultra-sensitive ATMOS image sensor that was originally developed for the most advanced displacement sensor, CDX Series.
CD2H Series is able to perform measurement even black objects that absorb light, which are difficult to detect with displacement sensors.
ATMOS: Auto Tuning C-MOS
-
- IO-Link compatible
- CD2H Series is the IO-Link compatible sensor.
You can connect to a variety of field networks by connecting to
IO-Link Master.
Measurement values can be obtained as digital values,
realizing highly accurate measurement without loss due to A/D conversion.
