Specifications
Technical Data
| Type | Plastic housing | Metal housing | |
|---|---|---|---|
| NPN | Cable type | BGS-CP30N | BGS-CM30N |
| Connector type | BGS-CP30CN | BGS-CM30CN | |
| PNP | Cable type | BGS-CP30P | BGS-CM30P |
| Connector type | BGS-CP30CP | BGS-CM30CP | |
| Sensing distance* | 300 mm | ||
| Adjustable distance range* | 30 to 300mm | ||
| Light source | Red LED | ||
| Spot size | Approx. ø15 mm / 300 mm | ||
| Response time | 1 ms or less | ||
| Hysteresis* | 10% | ||
| Distance adjustment | 4 turn pot. | ||
| Indicators | Output indicator (orange) / Stability indicator (green) | ||
| Control output | NPN/PNP type open collector Max. 100 mA/30 VDC | ||
| Output mode | Light ON / Dark ON selectable by control wire | ||
| Connection | 2m cable / M12 4-pin connecter | ||
| Rating | Supply voltage | 10 to 30 VDC, including 10% ripple (p-p) | |
| Current consumption | 35 mA or less | ||
| Applicable regulations |
EMC | EMC directive (2014/30/EU) | |
| Environment | |||
| Applicable standards | EN 60947-5-2 | ||
| NRTL Certification | UL Recognized Component(Cable type), UL Listed Component(M12 Connector type) |
||
| Environmental resistance | Ambient temperature / humidity |
-25 to +55℃ (no freezing) / 35 to 85%RH (no condensation) | |
| Storage temperature / humidity | -30 to +70℃ / 35 to 95%RH (no condensation) | ||
| Ambient illuminance | Sunlight: 10,000 lux, Incandescent lamp: 3,000 lux max. | ||
| Vibration resistance | 10 to 55 Hz; double amplitude 1.5 mm ; 2 hours in each of the X, Y, and Z directions |
||
| Shock resistance | Approx. 50 G (500 m/s2) ; 3 times in each of the X, Y, and Z directions |
||
| Degree of protection | IP67 | ||
| Material | Front Cover / Lens: PMMA |
Housing: BSBM, |
|
* White Paper 90%
• Specifications are subject to change without prior notice for product improvement purposes.
Typical characteristic data
BGS-CM30□ / BGS-CP30□
