Specifications
Technical Data
| Illumination color | White | |
|---|---|---|
| Color temperature | 6,000 K | |
| Input voltage | 12 VDC *Connect to dedicated controller. *OPPF flash overdrive not supported. | |
| Illumination conditions | Illumination control duty*: 10% or less, Continuous lighting width: 10 seconds or less | |
| Temperature protection | OPR-F32-10W OPR-SF55-28W |
Built-in temperature protection circuit (automatic shutoff if internal temperature reaches 80℃ or more, automatic recovery if internal temperature reaches 70℃ or less) Error with OPPF temperature monitor: ±5℃ (typical value) |
| OPR-SF70-43W OPR-SF85-58W |
Built-in temperature protection circuit (automatic shutoff if internal temperature reaches 60℃ or more, automatic recovery if internal temperature reaches 55℃ or less) Error with OPPF temperature monitor: ±10℃ (typical value) | |
| Degradation of LED | For brightness to drop 10% after 7,000 hours, Conditions: Dimming value setting = 100%, ambient environment = 30℃ (typical value) |
|
| Classification (IEC62471: 2006) | Risk group 1 (low risk) (Risk classification based on IEC 62471: 2006) | |
| Applicable regulations/standards | EMC (2014/30/EU), RoHS (2011/65/EU, MIIT Order No.32) / EN 61326-1:2013 Protection rating IP40 (IEC 60529: 1989/A1: 1999 + A2: 2013) | |
| Ambient temperature/humidity | 0 to 40℃ / 35 to 85% RH (no condensation) | |
| Storage temperature/humidity | -20 to 70℃ / 35 to 95% RH (no condensation) | |
| Vibration resistance | 10 to 55 Hz; amplitude 1.5 mm; 2 hours in each of the X, Y, and Z directions | |
| Shock resistance | 10 G, 3 times in each of the X, Y, and Z directions | |
| Material | Housing: ADC12 and PC, Lens: PC (UV-resistant) and PMMA | |
| Options | Low-angle attachment, diffusion plate (60% or 80%), transparent cover, polarizing plate, bracket, dual-side scratch-resistant cover |
|
- The illumination control duty is the illumination time percentage for a flash cycle.
Emission spectrum diagram
