IO-Link GatewayUC2 Series

Gateway unit to connect fiber sensors or
displacement sensor amplifiers to IO-Link Master

  • Max. 16 units of fiber sensor amplifier or 8 units of displacement sensor amplifier can be connected.
  • Fiber sensor amplifiers or displacement sensor amplifiers can be mixed connected.
  • Compact design, same size as fiber amplifier
