The OPX series is ideal for visually inspecting lead frames.
Using the OPX series of high-brightness, highly uniform, and high-directivity coaxial lighting, workpieces are illuminated in highly uniform light even from close range. The ability to ensure highly parallel lighting with no unevenness within the illumination area is ideal for fine scratch detection, dent detection, plating inspection, and other inspections for lead frames. In addition, the proprietary design ensures high brightness for image inspection at high shutter speeds.

BGS-HDL can be utilized for controlling start/stop of feeding of parts into parts feeder bowl.
Because BGS-HDL has 2 outputs and those threshold can be set individually, it can detect not only shortage of the parts but also over feeding.
You can reduce number of sensors from 2 to 1.

Obtain dimension inspection results for elongated connector leads.
The narrow directivity angle OPF series illuminates workpieces from the rear with a narrow directivity light angle and prevents unwanted reflected light and light leakage for clear contour extraction.
With a lineup featuring light-emitting surfaces between 50 × 15 to 210 × 200 mm, optimal lighting can be obtained for a variety of workpiece sizes.

Checking amount of coil wound by 2D displacement sensor LS series.
It can check distance in 27mm width maximum by laser line beam. It can measure deviation in that area as well as average.

Detecting edge of chip parts at the pick up nozzle.
By utilizing low angle attachment lens on the ring lighting OPR series, the edges of chip parts can be detected clearly without capturing pick up nozzle

Measurement height of the robot by CD22.
It measures height of the robot and feedback to the system to position the robot hand at correct position.
It can measure various material and very compact and light weight so you can install the sensor on the robot hand that moves often without problems.

The OPX-18 allows for visual inspection of microchip components.
With a cube beam splitter for its optical elements, the OPX-18 reduces ghosting seen in conventional half-mirror models for a higher-definition image.
This also allows for detection of fine scratches.
