Specifications
| Part No. | 14508 |
|---|---|
| Model | NF-TK05 |
| Category |
Cylindrical type Flexible type (R1 mm, R2 mm) |
| Type | ø3 |
| Detection method | Through-beam type |
| Optical axis direction | Straight view |
| Shape of fiber head |
ø3 mm 14 mm long |
| Sleeve | - |
| Optical axis diameter | ø1.0 mm |
| Fiber length | 2m |
| Free-cut | Possible |
| Min. bending radius | R2 mm |
| Degree of protection | - |
| Ambient temperature |
-40 ... +70°C 0 ... 40°C (at 85 % RH) |
| Ambient humidity | 35 ... 85 % RH |
| Applicable regulations | RoHS directive (2011/65/EU) |
| Weight | |
| Included items | Fiber cutter |
Sensing Distance by Response Time
Unit: mm
| Fiber-Optic Sensor D4RF Series | Fiber-Optic Sensor D12R Series | ||
|---|---|---|---|
|
3,600 (8 ms) 2,710 (2 ms) 2,010 (1 ms) 1,770 (500 μs) 1,415 (250 μs) 915 (70 μs) 310 (16 μs/22 μs) |
|
3,500 (4 ms) 2,010 (1 ms) 1,415 (250 μs) 495 (50 μs) |
Dimensions
Unit: mm
Accessories
| Type | Part No. | Model | |
|---|---|---|---|
| Fiber cutter |  |
20228 | NFC-F01 |
Correct Use
